Timber and joinery handling solutions need to control large, awkward panels as well as their weight. Kitchen worktops, cabinet doors, laminated boards and sheet materials may need to move from storage to cutting, finishing and assembly, often with a change of orientation along the way.
LiftRite supplies vacuum and mechanical lifting systems selected around the panel surface, dimensions, weight and workshop layout. The right arrangement supports the load while the operator guides it into position, reducing the need to carry and turn panels manually.
These LiftRite videos show sheet lifting and panel turning in practice. Select a preview to watch the equipment on YouTube.
The handling task: lifting and repositioning a large sheet while maintaining control of its face and edges.
The solution shown: a suspended vacuum lifting frame with multiple suction pads. The video demonstrates sheet handling with equipment offered for glass, steel or timber applications, subject to the load and surface.
For your joinery workshop: the pad layout must suit the panel dimensions and available gripping area. Surface finish, porosity, protective films and dust all need consideration before selecting a vacuum system. A test with your actual board helps confirm suitability.
The handling task: changing a panel's orientation between processing or assembly stages.
The project-specific solution: a vacuum lifter with a 180° tilt function, supporting the panel through the turning movement. The footage shows a panel held by the lifting frame as its orientation changes.
For your joinery workshop: allow space for the full turning movement, including the panel corners. Panel balance, pad positions, headroom and the receiving surface must be checked together. The permitted load depends on the selected lifter and operating orientation.
Smooth, sealed panels may be suitable for vacuum handling, but appearance alone is not enough to confirm a reliable grip. Unsealed boards, porous materials, textured finishes, cut-outs and dusty surfaces can change the vacuum requirements or limit usable contact areas. Where vacuum gripping is unsuitable, a mechanical attachment or another handling method may be needed.
LiftRite can discuss bespoke lifting attachments and handling systems around your actual material and production sequence. The supporting jib or gantry, available services and equipment capacity must be assessed as part of the complete system.
Send us a photo or short video of the task, your panel dimensions and weight, and the positions you need to move between. A sample of the material or surface finish will help us assess the gripping arrangement.
Discuss your panel handling requirement or call +353 1 601 6106.
