Key figures for Lift&Drive DC09 U52, presented for quick review.
| Capacity | Lift speed | Unit weight | Overall height | Length | Width |
|---|---|---|---|---|---|
| 90 kg | 132 mm/s | 85 kg | Up to 2839 mm / 52U | 960 mm | 565 mm |
See the detailed product information and specification documents below for full configuration details.
The Lift&Drive DC09 U52 lifts servers and batteries up to 90 kg across an approximate 1U–52U working range. Its telescopic mast retracts for lower doorways.
Four swivelling wheels, low rolling resistance and a rear-wheel central brake with directional lock support movement and positioning. Electric lift uses PRX control and a removable Ergoswap battery for charging outside the data hall.
DC09 U52 dimensions and performance.
| Maximum load | 90 kg |
|---|---|
| Working range | Approximately 1U–52U |
| Maximum lift speed | 132 mm/s |
| Minimum weight | 85 kg |
| Maximum height | 2,839 mm |
| Maximum length | 960 mm |
| Minimum width | 565 mm |
